Out Now! Introducing Mathcad 8

Resolving complex engineering calculations is one thing but communicating them visually is another. PTCs Mathcad Prime 8 introduces new easy to use 2D plotting capabilities that will help enhance the visualisation of your data.

Get the help you need faster. Help is now at your fingertips, and online, allowing you instant access to what you need when you need it.



What’s New in PTC Mathcad Prime 8?

Visualising your engineering calculations data is now even easier. PTC Mathcad Prime 8 provides a new comprehensive 2D plotting application that will enhance the way you annotate and deliver your engineering data.

Watch Now: Tips & Tricks in Mathcad Webinar

Boost Your 2D Plotting

Mathcad Prime 8 enables enhanced 2D plotting capabilities, allowing you to now fully customise the look and feel of your 2D plot charts.

Some of the enhanced formatting updates include:

  • Full Axes formatting
  • Titles and legend
  • Second Y-Axis
  • Gridlines
  • Customizable plot look and feel

Why Choose PTC Mathcad?

  • Securely communicate design intent and engineering knowledge
  • Intuitively construct calculations using standard math notation
  • Create professional-quality documents with live math, plots, text, and images
  • Repurpose standardized calculations
  • Increase productivity with full units support throughout calculations
  • Accelerate training and adoption with instant access to elearning

FEATURES & BENEFITS OF PTC MATHCAD



  • Simple to understand – there is no need for specialist programming skills
  • Enhances overall productivity, by optimising time use and decreasing errors
  • Increases accuracy of critical calculation verification and validation processes
  • Records all intellectual property and advocates calculation best practices and content reuse
  • Allows complete and protected management of calculations when integrated with Windchill
  • Total documentation of all calculation work, in support of standards compliance
